KR2511 Series
XHQ connector, single row, DIP Wafer, wire to board connector.
| Pitch | 2.50mm |
| Circuits: | 2-16pin |
| Current: | 3A |
| Voltage: | 250V |
KR2511 Series
Product Introducing
Select Components
Download
General Specifaction
| Material: | PA66/UL94/Phosphor Bronze/Brass |
| Insulation O.D | 1.2 to 1.6mm(MAX) |
| Withstanding Voltage: | 1000V AC/ minute |
| Temperature Range: | -40℃～+105℃ |
| Contact Resistance: | 20mΩ Max |
| Insulation Resistance: | 1000MΩ Min |
| Product Plating | Tin over Nickel |
