KR3810 Series 3.81mm 5-Pin Wire-to-Board Connector | KONNRA

A 3.81mm pitch 5-pin high-current wire-to-board socket connector rated at 8.0A/250V with gold-plated phosphor bronze contacts and PA6 housing for battery, power, and industrial equipment.

The KR3810 series is a heavy-duty, high-current 3.81 mm pitch 5-pin wire-to-board socket connector engineered for high-reliability DC power delivery, battery docking, and industrial power management. Designed in accordance with demanding industrial and power electrical standards, the KR3810 features precision-stamped phosphor bronze contacts with selective gold plating over a nickel underplate, achieving an exceptional current rating of 8.0A AC/DC per circuit and a voltage rating of 250V AC/DC.

The connector housing is molded from high-impact, heat-resistant PA6 thermoplastic (UL 94V-0) and integrates reinforced mounting side flanges (wings) measuring 36.70 mm wide. These lateral mounting ears provide superior mechanical stability, high anti-vibration resistance, and secure board retention during frequent mating cycles, making the KR3810 the premier interconnect choice for electric bicycle (e-bike) battery charging/discharging interfaces, energy storage systems (ESS), DC power distribution units, and motor controllers.

Pitch: 3.81mm (0.150″)
Circuits / Pins: 5 Pins (Single Row Socket)
Current Rating: 8.0A AC/DC
Voltage Rating: 250V AC/DC
Contact Plating: Selective Gold Plating over Nickel in Contact Area
Mechanical Feature: Reinforced Mounting Flanges / Side Wings (Width: 36.70mm)
Operating Temp: -40°C ~ +70°C

Key Specifications

Parameter Specification
Pitch 3.81mm (0.150″)
Circuits / Pins 5 Pins (Single Row Socket)
Current Rating 8.0A AC/DC
Voltage Rating 250V AC/DC
Contact Plating Selective Gold Plating over Nickel in Contact Area
Mechanical Feature Reinforced Mounting Flanges / Side Wings (Width: 36.70mm)
Operating Temp -40°C ~ +70°C

Engineering Selection Guidance

Review pitch, circuit count, current and voltage, wire size, mating interface, retention feature and operating environment against your project requirements.

Project Review Information

Send the part number, mating component requirements, wire size, application environment, BOM or drawing, and target quantity for engineering review.

Validation Boundary

Final connector selection and any cross-reference decision require project-specific review and validation.

Request Technical Information

Send your BOM or drawing for project review or request samples or technical information.

KR3810 Series 3.81mm 5-Pin Wire-to-Board Connector | KONNRA


    Select Components

    No results found.
    HousingTerminalWafer

    Download

    General Specifaction

    Part Number: H381001058001A (Drawing: 3810WFRD101-A-S)
    Pitch: 3.81 mm
    Number of Circuits: 5 Pin (5P Single Row Socket)
    Insulator Housing Material: PA6 Plastic (Polyamide 6, UL 94V-0)
    Contact Terminal Material: Phosphor Bronze (High Elasticity & Conductivity)
    Contact Plating: Nickel Plating and Gold Plating in the Contact Area
    Current Rating: 8.0A AC, DC Max.
    Voltage Rating: 250V AC, DC Max.
    Operating Temperature: -40°C ~ +70°C
    Contact Resistance: ≤ 20mΩ Max.
    Insulation Resistance: ≥ 500MΩ Min. (500V DC)
    Dielectric Withstanding Voltage: 500V AC / 1 minute (No breakdown / flashover)
    Overall Flange Width: 36.70 ± 0.28 mm (Mounting Wings)
    Housing Body Dimensions: 18.94 ± 0.3 mm (W) × 13.60 ± 0.2 mm (H) × 17.60 ± 0.3 mm (D)
    Contact Entry Gap: 1.40 ± 0.4 mm entry / 0.40 ± 0.2 mm contact spring gap
    Environmental Compliance: RoHS & REACH Compliant, Lead-Free Process Compatible

    Circuits & Dimensions (Part No. H381001058001A, Drawing No. 3810WFRD101-A-S)

    Circuits Part Number Drawing Number Pitch Overall Width (with Wings) Body Width Height
    5P H381001058001A 3810WFRD101-A-S 3.81 mm 36.70 ± 0.28 mm 18.94 ± 0.30 mm 13.60 ± 0.20 mm

    * Precision socket contact design with gold-plated phosphor bronze terminals, reinforced dual side mounting flanges, and full RoHS compliance.

    Overview

    The KONNRA KR3810 series is a heavy-duty 3.81 mm pitch 5-pin wire-to-board power socket connector designed for demanding power distribution and battery interconnect systems. Engineered to handle continuous operating currents up to 8.0A AC/DC at 250V AC/DC, the KR3810 delivers a highly reliable, low-resistance interface (≤20mΩ Max.) that bridges wire harnesses directly to control boards and battery terminals.

    Built with precision-formed phosphor bronze spring contacts featuring selective gold plating over a robust nickel underplate, the KR3810 guarantees superior anti-corrosion, resistance to fretting corrosion, and stable contact pressure over extended mating cycles. The housing is molded from high-mechanical-strength PA6 engineering plastic and features integrated lateral mounting wings with an overall width of 36.70 mm, ensuring exceptional anti-vibration stability and structural ruggedness in high-vibration applications such as electric bicycle (e-bike) battery docks, portable power stations, and industrial motor controllers.

    Key Advantages of KR3810 Series

    • High-Current 8.0A Capacity per Contact: Engineered with heavy-duty phosphor bronze contact blades capable of handling sustained 8.0A continuous current at 250V AC/DC, making it ideal for DC power delivery and battery charging/discharging lines.
    • Selective Gold Plating in Contact Area: High-durability gold plating over nickel barrier plate delivers an ultra-low contact resistance of ≤20mΩ, preventing contact oxidation and ensuring consistent electrical performance across hundreds of insertion/withdrawal cycles.
    • Reinforced Side Mounting Flanges (Wings): 36.70mm wide integral mounting ears provide robust screw or slot panel mounting, absorbing mechanical insertion stresses and preventing PCB solder joint fatigue under intense vibration.
    • Optimized 3.81mm Pitch Geometry: Generous 3.81mm centerline spacing ensures high dielectric clearance, easily meeting 500V AC dielectric withstanding voltage and preventing electrical creepage or short circuits.
    • Rugged PA6 Thermoplastic Construction: High-strength PA6 insulator body provides excellent impact resistance, wide temperature endurance from -40°C to +70°C, and full compliance with RoHS environmental standards.

    Application

    Target Industries and Application Scenarios

    The KR3810 series 3.81mm 5-pin high-current socket connector is widely deployed across e-mobility, clean energy, and industrial automation sectors:

    • Electric Mobility & E-Bike Battery Systems (Bike Charging / Discharging Interfaces):
      • Electric bicycle (E-bike) battery pack charging and power output docking ports (Power +, Power -, GND, NTC Temperature Sensor, Communication Signal)
      • Electric scooters, mopeds, and light electric vehicles (LEV) auxiliary power connections
      • Removable battery cartridge docking bays and smart battery exchange stations
    • Energy Storage Systems (ESS) & Portable Power Stations:
      • Modular lithium battery pack interconnects and DC output sockets
      • Solar energy storage battery management system (BMS) power links
      • Outdoor portable power station DC auxiliary ports and charging interfaces
    • Industrial Power Supplies & Motor Drives:
      • Switching power supply (SMPS) DC output headers and busbar taps
      • Industrial robotic controllers, stepper/servo motor driver boards
      • Modular DC-DC converter cards and power distribution backplanes
    • Commercial & Smart Equipment: Commercial kitchen equipment, automated vending machines, fitness equipment power modules, and smart agricultural machinery controllers.
