KR3961 Equivalent/Substitute Connector Cross List
Konnra VH Series Replacement/Alternative Product Database
| Brand 进口品牌 | Brand MPN 进口料号 | Konnra MPN Series 康瑞料号 | Compatible Series 兼容系列 | KONNRA Product Series 康瑞产品系列 | Pitch 间距 | Spec 规格 | Standard 标准 |
|---|---|---|---|---|---|---|---|
| JST | VHR-2N | H396101020101A | VH3.96 Housing 2P | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | VHR-3N | H396101030101A | VH3.96 Housing 3P | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | VHR-4N | H396101040101A | VH3.96 Housing 4P | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | VHR-5N | H396101050101A | VH3.96 Housing 5P | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | VHR-6N | H396101060101A | VH3.96 Housing 6P | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | VHR-7N | H396101070101A | VH3.96 Housing 7P | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | VHR-8N | H396101080101A | VH3.96 Housing 8P | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | VHR-9N | H396101090101A | VH3.96 Housing 9P | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | VHR-10N | H396101100101A | VH3.96 Housing 10P | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | VHR-11N | H396101110101A | VH3.96 Housing 11P | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | SVH-21T-P1.1 | T39610PT0101A | VH3.96 Terminal 磷铜 先镀锡后冲 | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | B2PS-VH | C3961RD10201T0101PA | VH3.96 DIP 90°WF 2P 袋装 | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | B3PS-VH | C3961RD10301T0101PA | VH3.96 DIP 90°WF 3P 袋装 | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | B4PS-VH | C3961RD10401T0101PA | VH3.96 DIP 90°WF 4P 袋装 | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | B5PS-VH | C3961RD10501T0101PA | VH3.96 DIP 90°WF 5P 袋装 | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | B6PS-VH | C3961RD10601T0101PA | VH3.96 DIP 90°WF 6P 袋装 | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | B7PS-VH | C3961RD10701T0101PA | VH3.96 DIP 90°WF 7P 袋装 | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | B8PS-VH | C3961RD10801T0101PA | VH3.96 DIP 90°WF 8P 袋装 | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | B9PS-VH | C3961RD10901T0101PA | VH3.96 DIP 90°WF 9P 袋装 | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | B10PS-VH | C3961RD11001T0101PA | VH3.96 DIP 90°WF 10P 袋装 | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | B2P-VH | C3961VD10201T0101PA | VH3.96 DIP 180°WF 2P 袋装 | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | B3P-VH | C3961VD10301T0101PA | VH3.96 DIP 180°WF 3P 袋装 | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | B4P-VH | C3961VD10401T0101PA | VH3.96 DIP 180°WF 4P 袋装 | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | B5P-VH | C3961VD10501T0101PA | VH3.96 DIP 180°WF 5P 袋装 | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | B6P-VH | C3961VD10601T0101PA | VH3.96 DIP 180°WF 6P 袋装 | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | B7P-VH | C3961VD10701T0101PA | VH3.96 DIP 180°WF 7P 袋装 | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | B8P-VH | C3961VD10801T0101PA | VH3.96 DIP 180°WF 8P 袋装 | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | B9P-VH | C3961VD10901T0101PA | VH3.96 DIP 180°WF 9P 袋装 | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
| JST | B10P-VH | C3961VD11001T0101PA | VH3.96 DIP 180°WF 10P 袋装 | KR3961 | 3.96mm | wire to board 线对板 | RoHS/REACH |
