KR2014 Equivalent/Substitute Connector Cross List
Konnra JST PA 2.0 Series Replacement/Alternative Product Database
| Brand 进口品牌 | Brand MPN 进口料号 | Konnra MPN Series 康瑞料号 | Compatible Series 兼容系列 | KONNRA Product Series 康瑞产品系列 | Pitch 间距 | Spec 规格 | Standard 标准 |
|---|---|---|---|---|---|---|---|
| JST | PAP-02V-S | H201401020101A | PA2.0 Housing 2P 白色 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 LV214 |
| JST | PAP-03V-S | H201401030101A | PA2.0 Housing 3P 白色 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | PAP-04V-S | H201401040101A | PA2.0 Housing 4P 白色 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | PAP-05V-S | H201401050101A | PA2.0 Housing 5P 白色 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | PAP-06V-S | H201401060101A | PA2.0 Housing 6P 白色 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | PAP-07V-S | H201401070101A | PA2.0 Housing 7P 白色 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | PAP-08V-S | H201401080101A | PA2.0 Housing 8P 白色 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | PAP-09V-S | H201401090101A | PA2.0 Housing 9P 白色 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | PAP-10V-S | H201401100101A | PA2.0 Housing 10P 白色 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | PAP-11V-S | H201401110101A | PA2.0 Housing 11P 白色 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | PAP-12V-S | H201401120101A | PA2.0 Housing 12P 白色 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | PAP-13V-S | H201401130101A | PA2.0 Housing 13P 白色 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | PAP-14V-S | H201401140101A | PA2.0 Housing 14P 白色 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | PAP-15V-S | H201401150101A | PA2.0 Housing 15P 白色 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | SPHD-001T-P0.5 SPHD-002T-P0.5 | T20050PT0101A | PHD/PA2.0 Terminal 磷铜 先冲后镀锡 | KR2005 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | S02B-PASK-2 | C2014RD10211M0101PA | PA2.0 DIP 90°WF 2P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | S03B-PASK-2 | C2014RD10311M0101PA | PA2.0 DIP 90°WF 3P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | S04B-PASK-2 | C2014RD10411M0101PA | PA2.0 DIP 90°WF 4P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | S05B-PASK-2 | C2014RD10511M0101PA | PA2.0 DIP 90°WF 5P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | S06B-PASK-2 | C2014RD10611M0101PA | PA2.0 DIP 90°WF 6P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | S07B-PASK-2 | C2014RD10711M0101PA | PA2.0 DIP 90°WF 7P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | S08B-PASK-2 | C2014RD10811M0101PA | PA2.0 DIP 90°WF 8P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | S03B-PASK-2 | C2014RD10311M0101PA | PA2.0 DIP 90°WF 9P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | S04B-PASK-2 | C2014RD10411M0101PA | PA2.0 DIP 90°WF 10P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | S05B-PASK-2 | C2014RD10511M0101PA | PA2.0 DIP 90°WF 11P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | S06B-PASK-2 | C2014RD10611M0101PA | PA2.0 DIP 90°WF 12P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | S07B-PASK-2 | C2014RD10711M0101PA | PA2.0 DIP 90°WF 13P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | S08B-PASK-2 | C2014RD10811M0101PA | PA2.0 DIP 90°WF 14P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | S15B-PASK-2 | C2014RD11511M0101PA | PA2.0 DIP 90°WF 15P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B02B-PASK | C2014VD10211M0103PA | PA2.0 DIP 180°WF 2P 无柱 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B03B-PASK | C2014VD10311M0103PA | PA2.0 DIP 180°WF 3P 无柱 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B04B-PASK | C2014VD10411M0103PA | PA2.0 DIP 180°WF 4P 无柱 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B05B-PASK | C2014VD10511M0103PA | PA2.0 DIP 180°WF 5P 无柱 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B06B-PASK | C2014VD10611M0103PA | PA2.0 DIP 180°WF 6P 无柱 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B07B-PASK | C2014VD10711M0103PA | PA2.0 DIP 180°WF 7P 无柱 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B08B-PASK | C2014VD10811M0103PA | PA2.0 DIP 180°WF 8P 无柱 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B09B-PASK | C2014VD10911M0103PA | PA2.0 DIP 180°WF 9P 无柱 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B10B-PASK | C2014VD11011M0103PA | PA2.0 DIP 180°WF 10P 无柱 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B11B-PASK | C2014VD11111M0103PA | PA2.0 DIP 180°WF 11P 无柱 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B12B-PASK | C2014VD11211M0103PA | PA2.0 DIP 180°WF 12P 无柱 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B13B-PASK | C2014VD11311M0103PA | PA2.0 DIP 180°WF 13P 无柱 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B14B-PASK | C2014VD11411M0103PA | PA2.0 DIP 180°WF 14P 无柱 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B15B-PASK | C2014VD11511M0103PA | PA2.0 DIP 180°WF 15P 无柱 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B02B-PASK-1 | C2014VD10211M0101PA | PA2.0 DIP 180°WF 2P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B03B-PASK-1 | C2014VD10311M0101PA | PA2.0 DIP 180°WF 3P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B04B-PASK-1 | C2014VD10411M0101PA | PA2.0 DIP 180°WF 4P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B05B-PASK-1 | C2014VD10511M0101PA | PA2.0 DIP 180°WF 5P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B06B-PASK-1 | C2014VD10611M0101PA | PA2.0 DIP 180°WF 6P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B07B-PASK-1 | C2014VD10711M0101PA | PA2.0 DIP 180°WF 7P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B08B-PASK-1 | C2014VD10811M0101PA | PA2.0 DIP 180°WF 8P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B09B-PASK-1 | C2014VD10911M0101PA | PA2.0 DIP 180°WF 9P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B10B-PASK-1 | C2014VD11011M0101PA | PA2.0 DIP 180°WF 10P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B11B-PASK-1 | C2014VD11111M0101PA | PA2.0 DIP 180°WF 11P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B12B-PASK-1 | C2014VD11211M0101PA | PA2.0 DIP 180°WF 12P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B13B-PASK-1 | C2014VD11311M0101PA | PA2.0 DIP 180°WF 13P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B14B-PASK-1 | C2014VD11411M0101PA | PA2.0 DIP 180°WF 14P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | B15B-PASK-1 | C2014VD11511M0101PA | PA2.0 DIP 180°WF 15P 袋装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | SM02B-PASS | C2014RS10211M0101RA | PA2.0 SMT 90°WF 2P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | SM03B-PASS | C2014RS10311M0101RA | PA2.0 SMT 90°WF 3P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | SM04B-PASS | C2014RS10411M0101RA | PA2.0 SMT 90°WF 4P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | SM05B-PASS | C2014RS10511M0101RA | PA2.0 SMT 90°WF 5P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | SM06B-PASS | C2014RS10611M0101RA | PA2.0 SMT 90°WF 6P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | SM07B-PASS | C2014RS10711M0101RA | PA2.0 SMT 90°WF 7P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | SM08B-PASS | C2014RS10811M0101RA | PA2.0 SMT 90°WF 8P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | SM09B-PASS | C2014RS10911M0101RA | PA2.0 SMT 90°WF 9P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | SM10B-PASS | C2014RS11011M0101RA | PA2.0 SMT 90°WF 10P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | SM11B-PASS | C2014RS11111M0101RA | PA2.0 SMT 90°WF 11P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | SM12B-PASS | C2014RS11211M0101RA | PA2.0 SMT 90°WF 12P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | SM13B-PASS | C2014RS11311M0101RA | PA2.0 SMT 90°WF 13P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | SM14B-PASS | C2014RS11411M0101RA | PA2.0 SMT 90°WF 14P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | SM15B-PASS | C2014RS11511M0101RA | PA2.0 SMT 90°WF 15P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | BM02B-PASS | C2014VS10211M0101RA | PA2.0 SMT 180°WF 2P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | BM03B-PASS | C2014VS10311M0101RA | PA2.0 SMT 180°WF 3P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | BM04B-PASS | C2014VS10411M0101RA | PA2.0 SMT 180°WF 4P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | BM05B-PASS | C2014VS10511M0101RA | PA2.0 SMT 180°WF 5P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | BM06B-PASS | C2014VS10611M0101RA | PA2.0 SMT 180°WF 6P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | BM07B-PASS | C2014VS10711M0101RA | PA2.0 SMT 180°WF 7P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | BM08B-PASS | C2014VS10811M0101RA | PA2.0 SMT 180°WF 8P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | BM09B-PASS | C2014VS10911M0101RA | PA2.0 SMT 180°WF 9P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | BM10B-PASS | C2014VS11011M0101RA | PA2.0 SMT 180°WF 10P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | BM11B-PASS | C2014VS11111M0101RA | PA2.0 SMT 180°WF 11P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | BM12B-PASS | C2014VS11211M0101RA | PA2.0 SMT 180°WF 12P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | BM13B-PASS | C2014VS11311M0101RA | PA2.0 SMT 180°WF 13P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | BM14B-PASS | C2014VS11411M0101RA | PA2.0 SMT 180°WF 14P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
| JST | BM15B-PASS | C2014VS11511M0101RA | PA2.0 SMT 180°WF 15P 卷装 | KR2014 | 2.0mm | wire to board 线对板 | RoHS/REACH LV214 |
