KR1501 Equivalent/Substitute Connector Cross List
Konnra ZH1.5 Series Replacement/Alternative Product Database
| Brand 进口品牌 |
Brand MPN 进口料号 |
Konnra MPN Series 康瑞料号 |
Compatible Series 兼容系列 |
KONNRA Product Series 康瑞产品系列 |
Pitch 间距 |
Spec 规格 |
Standard 标准 |
|---|---|---|---|---|---|---|---|
| JST | ZHR-2 | H150101020101A | ZH1.5 Housing 2P (方孔) | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | ZHR-3 | H150101030101A | ZH1.5 Housing 3P (方孔) | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | ZHR-4 | H150101040101A | ZH1.5 Housing 4P (方孔) | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | ZHR-5 | H150101050101A | ZH1.5 Housing 5P (方孔) | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | ZHR-6 | H150101060101A | ZH1.5 Housing 6P (方孔) | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | ZHR-7 | H150101070101A | ZH1.5 Housing 7P (方孔) | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | ZHR-8 | H150101080101A | ZH1.5 Housing 8P (方孔) | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | ZHR-9 | H150101090101A | ZH1.5 Housing 9P (方孔) | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | ZHR-10 | H150101100101A | ZH1.5 Housing 10P (方孔) | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | ZHR-11 | H150101110101A | ZH1.5 Housing 11P (方孔) | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | ZHR-12 | H150101120101A | ZH1.5 Housing 12P (方孔) | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | ZHR-13 | H150101130101A | ZH1.5 Housing 13P (方孔) | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | 无 | H150101140101A | ZH1.5 Housing 14P (方孔) | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | 无 | H150101150101A | ZH1.5 Housing 15P (方孔) | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | 无 | H150101160101A | ZH1.5 Housing 16P (方孔) | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | SZH-002T-P0.5 SZH-003T-P0.5 | T15010PT0101A | ZH1.5 Terminal 磷铜 先冲后镀锡 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S2B-ZR | C1501RD10209T0101PA | ZH1.5 DIP 90°WF 2P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S3B-ZR | C1501RD10209T0101PA | ZH1.5 DIP 90°WF 3P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S4B-ZR | C1501RD10209T0101PA | ZH1.5 DIP 90°WF 4P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S5B-ZR | C1501RD10209T0101PA | ZH1.5 DIP 90°WF 5P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S6B-ZR | C1501RD10209T0101PA | ZH1.5 DIP 90°WF 6P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S7B-ZR | C1501RD10209T0101PA | ZH1.5 DIP 90°WF 7P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S8B-ZR | C1501RD10209T0101PA | ZH1.5 DIP 90°WF 8P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S9B-ZR | C1501RD10209T0101PA | ZH1.5 DIP 90°WF 9P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S10B-ZR | C1501RD10209T0101PA | ZH1.5 DIP 90°WF 10P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S11B-ZR | C1501RD10209T0101PA | ZH1.5 DIP 90°WF 11P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S12B-ZR | C1501RD10209T0101PA | ZH1.5 DIP 90°WF 12P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S13B-ZR | C1501RD10209T0101PA | ZH1.5 DIP 90°WF 13P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S2B-ZR-3.4 | C1501RD10219T0103PA | ZH1.5 DIP 90°WF 2P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S3B-ZR-3.4 | C1501RD10319T0103PA | ZH1.5 DIP 90°WF 3P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S4B-ZR-3.4 | C1501RD10419T0103PA | ZH1.5 DIP 90°WF 4P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S5B-ZR-3.4 | C1501RD10519T0103PA | ZH1.5 DIP 90°WF 5P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S6B-ZR-3.4 | C1501RD10619T0103PA | ZH1.5 DIP 90°WF 6P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S7B-ZR-3.4 | C1501RD10719T0103PA | ZH1.5 DIP 90°WF 7P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S8B-ZR-3.4 | C1501RD10819T0103PA | ZH1.5 DIP 90°WF 8P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S9B-ZR-3.4 | C1501RD10919T0103PA | ZH1.5 DIP 90°WF 9P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S10B-ZR-3.4 | C1501RD11019T0103PA | ZH1.5 DIP 90°WF 10P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S11B-ZR-3.4 | C1501RD11119T0103PA | ZH1.5 DIP 90°WF 11P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S12B-ZR-3.4 | C1501RD11219T0103PA | ZH1.5 DIP 90°WF 12P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S13B-ZR-3.4 | C1501RD11319T0103PA | ZH1.5 DIP 90°WF 13P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B2B-ZR | C1501VD10209T0101PA | ZH1.5 DIP 180°WF 2P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B3B-ZR | C1501VD10209T0101PA | ZH1.5 DIP 180°WF 3P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B4B-ZR | C1501VD10209T0101PA | ZH1.5 DIP 180°WF 4P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B5B-ZR | C1501VD10209T0101PA | ZH1.5 DIP 180°WF 5P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B6B-ZR | C1501VD10209T0101PA | ZH1.5 DIP 180°WF 6P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B7B-ZR | C1501VD10209T0101PA | ZH1.5 DIP 180°WF 7P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B8B-ZR | C1501VD10209T0101PA | ZH1.5 DIP 180°WF 8P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B9B-ZR | C1501VD10209T0101PA | ZH1.5 DIP 180°WF 9P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B10B-ZR | C1501VD10209T0101PA | ZH1.5 DIP 180°WF 10P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B11B-ZR | C1501VD10209T0101PA | ZH1.5 DIP 180°WF 11P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B12B-ZR | C1501VD10209T0101PA | ZH1.5 DIP 180°WF 12P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B13B-ZR | C1501VD10209T0101PA | ZH1.5 DIP 180°WF 13P 打K 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B2B-ZR-3.4 | C1501VD10219T010*PA | ZH1.5 DIP 90°WF 2P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B3B-ZR-3.4 | C1501VD10319T010*PA | ZH1.5 DIP 90°WF 3P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B4B-ZR-3.4 | C1501VD10419T010*PA | ZH1.5 DIP 90°WF 4P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B5B-ZR-3.4 | C1501VD10519T010*PA | ZH1.5 DIP 90°WF 5P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B6B-ZR-3.4 | C1501VD10619T010*PA | ZH1.5 DIP 90°WF 6P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B7B-ZR-3.4 | C1501VD10719T010*PA | ZH1.5 DIP 90°WF 7P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B8B-ZR-3.4 | C1501VD10819T010*PA | ZH1.5 DIP 90°WF 8P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B9B-ZR-3.4 | C1501VD10919T010*PA | ZH1.5 DIP 90°WF 9P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B10B-ZR-3.4 | C1501VD11019T010*PA | ZH1.5 DIP 90°WF 10P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B11B-ZR-3.4 | C1501VD11119T010*PA | ZH1.5 DIP 90°WF 11P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B12B-ZR-3.4 | C1501VD11219T010*PA | ZH1.5 DIP 90°WF 12P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B13B-ZR-3.4 | C1501VD11319T010*PA | ZH1.5 DIP 90°WF 13P 不打K DIP=3.4 袋装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S2B-ZR-SM4A-TF | C1501RS10211M0101RA | ZH1.5 SMT 90°WF 2P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S3B-ZR-SM4A-TF | C1501RS10311M0101RA | ZH1.5 SMT 90°WF 3P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S4B-ZR-SM4A-TF | C1501RS10411M0101RA | ZH1.5 SMT 90°WF 4P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S5B-ZR-SM4A-TF | C1501RS10511M0101RA | ZH1.5 SMT 90°WF 5P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S6B-ZR-SM4A-TF | C1501RS10611M0101RA | ZH1.5 SMT 90°WF 6P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S7B-ZR-SM4A-TF | C1501RS10711M0101RA | ZH1.5 SMT 90°WF 7P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S8B-ZR-SM4A-TF | C1501RS10811M0101RA | ZH1.5 SMT 90°WF 8P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S9B-ZR-SM4A-TF | C1501RS10911M0101RA | ZH1.5 SMT 90°WF 9P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S10B-ZR-SM4A-TF | C1501RS11011M0101RA | ZH1.5 SMT 90°WF 10P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S11B-ZR-SM4A-TF | C1501RS11111M0101RA | ZH1.5 SMT 90°WF 11P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S12B-ZR-SM4A-TF | C1501RS11211M0101RA | ZH1.5 SMT 90°WF 12P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | S13B-ZR-SM4A-TF | C1501RS11311M0101RA | ZH1.5 SMT 90°WF 13P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | 无 | C1501RS11411M0101RA | ZH1.5 SMT 90°WF 14P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B2B-ZR-SM4-TF | C1501VS10211M0101RA | ZH1.5 SMT 180°WF 2P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B3B-ZR-SM4-TF | C1501VS10311M0101RA | ZH1.5 SMT 180°WF 3P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B4B-ZR-SM4-TF | C1501VS10411M0101RA | ZH1.5 SMT 180°WF 4P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B5B-ZR-SM4-TF | C1501VS10511M0101RA | ZH1.5 SMT 180°WF 5P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B6B-ZR-SM4-TF | C1501VS10611M0101RA | ZH1.5 SMT 180°WF 6P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B7B-ZR-SM4-TF | C1501VS10711M0101RA | ZH1.5 SMT 180°WF 7P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B8B-ZR-SM4-TF | C1501VS10811M0101RA | ZH1.5 SMT 180°WF 8P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B9B-ZR-SM4-TF | C1501VS10911M0101RA | ZH1.5 SMT 180°WF 9P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B10B-ZR-SM4-TF | C1501VS11011M0101RA | ZH1.5 SMT 180°WF 10P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B11B-ZR-SM4-TF | C1501VS11111M0101RA | ZH1.5 SMT 180°WF 11P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B12B-ZR-SM4-TF | C1501VS11211M0101RA | ZH1.5 SMT 180°WF 12P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | B13B-ZR-SM4-TF | C1501VS11311M0101RA | ZH1.5 SMT 180°WF 13P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
| JST | 无 | C1501VS11411M0101RA | ZH1.5 SMT 180°WF 14P 卷装 | KR1501 | 1.5mm | wire to board 线对板 | RoHS/REACH |
