KR1250 Equivalent/Substitute Connector Cross List
Konnra MX1.25 PicoBlade Series Replacement/Alternative Product Database
| Brand 进口品牌 |
Brand MPN 进口料号 |
Konnra MPN Series 康瑞料号 |
Compatible Series 兼容系列 |
KONNRA Product Series 康瑞产品系列 |
Pitch 间距 |
Spec 规格 |
Standard 标准 |
|---|---|---|---|---|---|---|---|
| Molex | 51021-0200 | H125001020101B | MX1.25 Housing 2P DDJ | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 51021-0300 | H125001030101B | MX1.25 Housing 3P DDJ | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 51021-0400 | H125001040101B | MX1.25 Housing 4P DDJ | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 51021-0500 | H125001050101B | MX1.25 Housing 5P DDJ | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 51021-0600 | H125001060101B | MX1.25 Housing 6P DDJ | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 51021-0700 | H125001070101B | MX1.25 Housing 7P DDJ | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 51021-0800 | H125001080101B | MX1.25 Housing 8P DDJ | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 51021-0900 | H125001090101B | MX1.25 Housing 9P DDJ | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 51021-1000 | H125001100101B | MX1.25 Housing 10P DDJ | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 51021-1100 | H125001110101B | MX1.25 Housing 11P DDJ | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 51021-1200 | H125001120101B | MX1.25 Housing 12P DDJ | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 51021-1300 | H125001130101B | MX1.25 Housing 13P DDJ | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 51021-1400 | H125001140101B | MX1.25 Housing 14P DDJ | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 51021-1500 | H125001150101B | MX1.25 Housing 15P DDJ | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 无 | H125001020101B | MX1.25 Housing 16P DDJ | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 50058-8000 | T1250FPT0101A | MX1.25 Terminal 磷铜 先冲后镀锡 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53047-0210 | C1250RD10213T0101PA | MX1.25 DIP 90°WF 2P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53047-0310 | C1250RD10313T0101PA | MX1.25 DIP 90°WF 3P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53047-0410 | C1250RD10413T0101PA | MX1.25 DIP 90°WF 4P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53047-0510 | C1250RD10513T0101PA | MX1.25 DIP 90°WF 5P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53047-0610 | C1250RD10613T0101PA | MX1.25 DIP 90°WF 6P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53047-0710 | C1250RD10713T0101PA | MX1.25 DIP 90°WF 7P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53047-0810 | C1250RD10813T0101PA | MX1.25 DIP 90°WF 8P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53047-0910 | C1250RD10913T0101PA | MX1.25 DIP 90°WF 9P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53047-1010 | C1250RD11013T0101PA | MX1.25 DIP 90°WF 10P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53047-1110 | C1250RD11113T0101PA | MX1.25 DIP 90°WF 11P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53047-1210 | C1250RD11213T0101PA | MX1.25 DIP 90°WF 12P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53047-1310 | C1250RD11313T0101PA | MX1.25 DIP 90°WF 13P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53047-1410 | C1250RD11413T0101PA | MX1.25 DIP 90°WF 14P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53047-1510 | C1250RD11513T0101PA | MX1.25 DIP 90°WF 15P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 无 | C1250RD11613T0101PA | MX1.25 DIP 90°WF 16P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53048-0210 | C1250VD10213T0101PA | MX1.25 DIP 180 WF 2P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53048-0310 | C1250VD10313T0101PA | MX1.25 DIP 180 WF 3P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53048-0410 | C1250VD10413T0101PA | MX1.25 DIP 180 WF 4P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53048-0510 | C1250VD10513T0101PA | MX1.25 DIP 180 WF 5P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53048-0610 | C1250VD10613T0101PA | MX1.25 DIP 180 WF 6P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53048-0710 | C1250VD10713T0101PA | MX1.25 DIP 180 WF 7P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53048-0810 | C1250VD10813T0101PA | MX1.25 DIP 180 WF 8P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53048-0910 | C1250VD10913T0101PA | MX1.25 DIP 180 WF 9P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53048-1010 | C1250VD11013T0101PA | MX1.25 DIP 180 WF 10P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53048-1110 | C1250VD11113T0101PA | MX1.25 DIP 180 WF 11P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53048-1210 | C1250VD11213T0101PA | MX1.25 DIP 180 WF 12P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53048-1310 | C1250VD11313T0101PA | MX1.25 DIP 180 WF 13P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53048-1410 | C1250VD11413T0101PA | MX1.25 DIP 180 WF 14P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53048-1510 | C1250VD11513T0101PA | MX1.25 DIP 180 WF 15P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 无 | C1250VD11613T0101PA | MX1.25 DIP 180 WF 16P LCP 袋装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53261-02** | C1250RS10213M0101RA | MX1.25 SMT 90°WF 2P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53261-03** | C1250RS10313M0101RA | MX1.25 SMT 90°WF 3P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53261-04** | C1250RS10413M0101RA | MX1.25 SMT 90°WF 4P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53261-05** | C1250RS10513M0101RA | MX1.25 SMT 90°WF 5P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53261-06** | C1250RS10613M0101RA | MX1.25 SMT 90°WF 6P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53261-07** | C1250RS10713M0101RA | MX1.25 SMT 90°WF 7P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53261-08** | C1250RS10813M0101RA | MX1.25 SMT 90°WF 8P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53261-09** | C1250RS10913M0101RA | MX1.25 SMT 90°WF 9P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53261-10** | C1250RS11013M0101RA | MX1.25 SMT 90°WF 10P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53261-11** | C1250RS11113M0102RA | MX1.25 SMT 90°WF 11P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53261-12** | C1250RS11213M0103RA | MX1.25 SMT 90°WF 12P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53261-13** | C1250RS11313M0104RA | MX1.25 SMT 90°WF 13P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53261-14** | C1250RS11413M0105RA | MX1.25 SMT 90°WF 14P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53261-15** | C1250RS11513M0106RA | MX1.25 SMT 90°WF 15P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 无 | C1250RS11613M0107RA | MX1.25 SMT 90°WF 16P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53398-02** | C1250VS10213M0101RA | MX1.25 SMT 180°WF 2P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53398-03** | C1250VS10313M0101RA | MX1.25 SMT 180°WF 3P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53398-04** | C1250VS10413M0101RA | MX1.25 SMT 180°WF 4P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53398-05** | C1250VS10513M0101RA | MX1.25 SMT 180°WF 5P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53398-06** | C1250VS10613M0101RA | MX1.25 SMT 180°WF 6P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53398-07** | C1250VS10713M0101RA | MX1.25 SMT 180°WF 7P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53398-08** | C1250VS10813M0101RA | MX1.25 SMT 180°WF 8P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53398-09** | C1250VS10913M0101RA | MX1.25 SMT 180°WF 9P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53398-10** | C1250VS11013M0101RA | MX1.25 SMT 180°WF 10P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53398-11** | C1250VS11113M0102RA | MX1.25 SMT 180°WF 11P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53398-12** | C1250VS11213M0103RA | MX1.25 SMT 180°WF 12P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53398-13** | C1250VS11313M0104RA | MX1.25 SMT 180°WF 13P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53398-14** | C1250VS11413M0105RA | MX1.25 SMT 180°WF 14P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 53398-15** | C1250VS11513M0106RA | MX1.25 SMT 180°WF 15P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
| Molex | 无 | C1250VS11613M0107RA | MX1.25 SMT 180°WF 16P LCP 卷装 | KR1250 | 1.25mm | wire to board 线对板 | RoHS/REACH |
